AL-T Heat Resistant Grease - 400gm Cartridge

SKU: SWM000529B01V0001
MPN: 26600040
Availability: Available for Fast Dispatch.
$20.17
INC. GST
$18.15
EX. GST
Container Size

BULK DISCOUNT RATES

All Bulk Prices Below Are Quoted Including GST.
Buy 5 - 9 and pay only $18.47 each
Buy 10 or above and pay only $17.91 each
  • High temperature, heat resistant grease for up to 190°C.
  • All-purpose grease used for bearings, levers, guides, spindles, shafts, wire ropes, chains and more.
  • Long term lubrication performance.

Our AL-T Heat Resistant Grease is a high quality, German-engineered lubricant designed for higher temperature applications. This all-round lubricant can withstand continuous exposure to temperatures between -25°C and +190°C.

It provides excellent lubrication performance and is water resistant and fast acting.

AL-T Allround lubricant is a universal style of grease that is used in a number of different industries as well as in household applications. It is based on aluminium complex soap and mineral oil and dark brown in colour.

More information on this high temp grease is provided in the sections below:

Highly Effective Lubrication for Reduced Friction.

AL-T Grease is an industrial-grade lubricant that reduces friction and helps prevent wear on stressed parts. This universal style grease has been designed specifically to withstand elevated temperatures and can handle continuous exposure to 190°C.

Abbreviation (DIN 51502) KPL 2 R-20
Consistency Assignment (DIN 51818) NLGI Class 2
Composition Aluminium Complex Soap / Mineral Oil
VKA-TEST (DIN 51350) Welding Load 2,400 N
VKA-TEST (DIN 51350) Goods Load 2,200 N
VKA-TEST (DIN 51350)
Spherical Cap Value (1Min/1000N)
2mm
Speed Identifying Value (ka . n . dm) 400,000
Worked Penetration (DIN ISO 2137) 265 - 295 1/10 mm
Water Resistance (DIN 51807) 0 – 90
Kinematic Viscosity (DIN 51562)
at +40°C
230mm²/s
Kinematic Viscosity (DIN 51562)
at +100°C
16mm²/s

Versatile, Can Be Used on Many Equipment Types.

Al-T Grease is able to be used on many different types of bearings, joints, levers, guides, spindles, shafts, gears and cables. The tables below provide a summary of the material and part types known to be compatible with this industrial grease.

Rolling Bearings Y
Sliding Bearings Y
Chains
Joints Y
Levers Y
Sliding Guides Y
Linear Guide Systems Y
Spindles Y
Spline Shafts Y
Camshafts
Springs
Open Gears
Worm Gears
Cables

Technical Specifications for AL-T Grease.

Abbreviation (DIN 51502) KP{L 2 R-20
Consistency Assignment (DIN 51818) NLGI Class 2
Composition Aluminium Complex Soap / Mineral Oil
Colour Dark Brown
Density at +20°C (+68°F) (DIN 51757) 0.94 g/cm³
VKA-TEST (DIN 51350) Welding Load 2,400 N
VKA-TEST (DIN 51350) Goods Load 2,200 N
VKA-TEST (DIN 51350)
Spherical Cap Value (1Min/1000N)
2mm
Speed Identifying Value (ka . n . dm) 400,000
Worked Penetration (DIN ISO 2137) 265 - 295 1/10 mm
Water Resistance (DIN 51807) 0 – 90
Drop Point (IP 396) > 210°C
Kinematic Viscosity (DIN 51562)
at +40°C
230mm²/s
Kinematic Viscosity (DIN 51562)
at +100°C
16mm²/s
EMCOR Corrosion Test (DIN 51 802): 0 / 0
Temperature Resistance -25°C to +190°C
Storage Stability 24 Months Minimum

Application Type Compatability for AL-T Grease.

Rolling Bearings Y
Sliding Bearings Y
Chains
Joints Y
Levers Y
Sliding Guides Y
Linear Guide Systems Y
Spindles Y
Spline Shafts Y
Camshafts
Springs
Open Gears
Worm Gears
Cables

AL-T Grease Compatability with Rubber Sealing Materials.

ACM – Acrylate Rubber ++
CR – Chloroprene Rubber +
CSM – Chlorosulfonated PE Rubber ++
EPDM – Ethylene Propylene Diene Rubber 0
FMK – Fluorocaoutchoc / Viton ++
NBR – Nitrile Butadiene Rubber ++
NR – Natural Rubber 0
SBR – Styrene Butadiene Rubber 0
SQM/MVQ – Silicone Rubber ++

AL-T Grease Compatability with Plastic, Polymer-Based Sealing Materials.

ABS ++
CA – Cellulose Acetate ++
EPS – Expanded Polystyrene ++
PA – Polyamide ++
PC – Polycarbonate 0
PE-UHMW – Ultra High Molecular Weight
Polyethylene (UHMWPE)
++
PE-LD Polyethylene with Low Density (LDPE) +
PET – Polyethyleneterephtalate ++
POM – Polyoxylmethylene ++
PP – Polypropylene ++
PPO – Polyphenylene Oxide ++
PS – Polystyrene +
PTFE – Polytetrafluoroethylene ++
PUR – Polyurethane +
PVC – Polyvinylchloride ++
TPE – Thermoplastic Elastomers 0

Compatibility Key Information.

++ = Compatible.
+ = Compatible to a limited extent.
0 = Not Compatible.

The stated compatibility and resistance levels are based on laboratory tests and literature notices. A guarantee cannot be provided due the large number of raw materials used on the one hand the complex chemical and morphological structure of the polymers on the other. In critical application cases we recommend that you carry out tests and/or consult with the Weicon application technology department.

SKU SWM000529B01
Brand Weicon
