3M Scotch Super 33+ Electrical Tape - 19mm Wide x 33 Metres

SKU: SWM000048B01V0001
Availability: Del.
$21.69
INC. GST
$19.52
EX. GST

BULK DISCOUNT RATES

All Bulk Prices Below Are Quoted Including GST.
Buy 4 - 7 and pay only $20.43 each
Buy 8 or above and pay only $20.02 each
  • Premium grade PVC tape that’s tough, strong, long lasting and UV resistant.
  • Pressure-sensitive rubber based adhesive.
  • Creates moisture-tight electrical and mechanical protection with minimal bulk.

3M Super 33+ Scotch Electrical Tape is a very high quality grade of polyvinyl chloride (PVC) electrical tape. This tape consists of an elastic backing coated on one side with an aggressive, pressure-sensitive rubber based adhesive that sticks to most surfaces. The resulting tape is highly conformable and can be applied neatly in tight wraps and to complex shapes.

3M Super 33+ is compatible with solid dielectric cable insulation as well as rubber and synthetic spicing compounds. It also works well with epoxy and polyurethane resins. It effectively resists moisture, alkalis, acids and abrasion and is also able to withstand variable weather conditions (including ultraviolet exposure) which allows it to be used indoors or outdoors.

3M Super 33+ Scotch Electrical Tape is black and able to withstand temperatures between -18°C and 105°C. It has a total thickness of 0.177mm.

3M and Scotch are trademarks of 3M.

Applications for 3M Scotch 33+ PVC Electrical Tape.

  • Weatherproofing electrical junctions, cables and connections
  • Harnessing or cables and wires
  • Protective jacketing for high voltage cable splices and repairs
  • Primary insulation for 600-volt bus applications
  • Primary insulation for wire and cable splices rated up to 600 volts and up to 105°C
Colour Black
Adhesive Rubber Pressure Sensitive Adhesive
Backing Material Polyvinyl Chloride (PVC)
Total Tape Thickness 0.177mm
Continuous Operating Temperature -18°C to +105°C
Dielectric Strength 1,150 V/mil
Ultimate Elongation 250% at 18°C (ASTM D 1000)
Adhesion to Steel 28 oz/in. (22°C, ASTM D 1000)
Roll Length 33 Metres



SKU SWM000048B01
Brand 3M

Technical Data Sheet.

Link to our Neoprene Sponge Tape TDS
3M Super 33+ Scotch Electrical Tape TDS

Related Content & Resources.

Quick Reference Guide Link
3M Scotch Super 33 Electrical Tape Quick Reference Guide


Does it stretch?

Yes. At 18°C 3M Super 33+ Scotch Electrical Tape has an ultimate elongation rating of 250%.

Are other colours available?

Not of this particular tape, no. 3M Temflex 1610 and Scotch 35 are both available in other colours though.
